Advantage
1. With a wide range of speed and feed, with manual\power and fine feeds.
2. The feed of machines are very easily engaged and disengaged at any time.
3. All parts are easily operated and changed.
4. High quality of casting.
5. Heat treatment for spindle parts, ensuring their high strength and durability.
6. Main gears are machined by gear grinding, ensuring the machine with high precision and low noise.
Standard accessories:
1. Keyless drill chuck;
2. Connecting rod;
3. Reduction sleeve;
4. Withdrawl wedge
1. With a wide range of speed and feed, with manual\power and fine feeds.
2. The feed of machines are very easily engaged and disengaged at any time.
3. All parts are easily operated and changed.
4. High quality of casting.
5. Heat treatment for spindle parts, ensuring their high strength and durability.
6. Main gears are machined by gear grinding, ensuring the machine with high precision and low noise.
| Model | Z3040x14/Z3040x11 |
| Fladial drilling machine | |
| Max. drilling dia | Iron Φ40/steel Φ32 |
| Distance from spindle nose to table surface | 260-1150/260-1050 |
| Distance between spindle axis and column surface | 350-1400/ 360-1/1100 |
| Spindle travel | 200 |
| Spindle cone | 4 |
| Spindle speed range | 78. 130. 240. 380. 660. 1200 |
| Spindle speed step | 6 |
| Spindle feeding range | 0.10-0.25 |
| Spindle feeding step | 3 |
| Rocker rotary angle | 360 |
| Main motor power | 2.2 |
| Movements motor power | 1.5/0.75 |
| N.W/G.W | 2200/1600 |
| Overall dimension | 1800x810x2300/1500x705x2200 |
| Hercules Machinery Equipment Ltd. | |
Standard accessories:
1. Keyless drill chuck;
2. Connecting rod;
3. Reduction sleeve;
4. Withdrawl wedge
